Double Girder Overhead Cranes
LH Type Double Girder Overhead Crane
Cost-effective LH series double girder crane with compact electric hoist. Lightweight design, low headroom, ideal for 5-32T general lifting in workshops.
Specifications
- Type
- LH Type Overhead Crane
- Girder
- Double Girder
- Span & Capacity
- Customized
LH Double Girder Overhead Crane with Electric Hoist
Product Overview
The LH model is a cost-effective double girder crane designed for medium-duty workshops. Unlike heavy winch cranes, it uses a compact electric wire rope hoist, offering a low headroom design that saves factory space and construction costs.
Key Advantages
- Lightweight Structure: Low dead weight and small wheel pressure reduce the load on your workshop columns.
- Space Saving: Compact hoist design maximizes lifting height within limited headroom.
- Easy Maintenance: Standardized electric hoist components make parts replacement simple and affordable.
- Smooth Operation: Features a three-in-one drive system for stable movement (VFD optional).
Technical Specifications
- Capacity: 5 Ton, 10 Ton, 16 Ton, 20 Ton, 32 Ton
- Span: 7.5m - 31.5m (Customizable)
- Lifting Height: 6m - 30m (Customizable)
- Work Duty: A3 - A5 (Medium Duty)
- Power Supply: 380V/50Hz/3Phase (415V/440V Available)
Standard Safety Features
Overload limiter, upper limit switch, emergency stop, and end buffers.
Common Applications
Ideal for machinery workshops, warehouses, assembly lines, and maintenance bays.
